Intel Core i3-14100F 4 Cores 8 Threads 58 W TDP 3.5 GHz Frequency 4.7 GHz Boost Raptor Lake-R Codename Socket 1700

Intel Core i3-14100F 4 Cores 8 Threads 58 W TDP 3.5 GHz Frequency 4.7 GHz Boost Raptor Lake-R Codename Socket 1700

Original price was: $119.00.Current price is: $109.00.

Guaranteed Safe Checkout

Features & Compatibility

The Intel Core i3-14100F is a desktop processor with 4 cores, launched in January 2024, at an MSRP of $109. It is part of the Core i3 lineup, using the Raptor Lake Refresh architecture with Socket 1700. Thanks to Intel Hyper-Threading the core-count is effectively doubled, to 8 threads. Core i3-14100F has 12 MB of L3 cache and operates at 3.5 GHz by default, but can boost up to 4.7 GHz, depending on the workload. Intel is building the Core i3-14100F on a 10 nm production process, the transistor count is unknown. The multiplier is locked on Core i3-14100F, which limits its overclocking capabilities.
With a TDP of 58 W, the Core i3-14100F consumes typical power levels for a modern PC. Intel’s processor supports DDR4 and DDR5 memory with a dual-channel interface. ECC memory is supported, too, which is an important capability for mission-critical systems, to avoid data corruption. For communication with other components in the machine, Core i3-14100F uses a PCI-Express Gen 5 connection. This processor does not have integrated graphics, you will need a separate graphics card. Inside the box you will not only find the processor, but also a Laminar RM1 cooler.
Hardware virtualization is available on the Core i3-14100F, which greatly improves virtual machine performance. Additionally, IOMMU virtualization (PCI passthrough) is supported, so that guest virtual machines may directly use host hardware. Programs using Advanced Vector Extensions (AVX) will run on this processor, boosting performance for calculation-heavy applications. Besides AVX, Intel is including the newer AVX2 standard, too, but not AVX-512.

Physical

Socket: Intel Socket 1700
Foundry: Intel
Process Size: 10 nm
Die Size: 163 mm²
Package: FC-LGA16A
tJMax: 100°C

Processor

Market: Desktop
Production Status: Active
Release Date: Jan 8th, 2024
Launch Price: $109
Part#: SRMX2
Bundled Cooler: Laminar RM1

Performance

Frequency: 3.5 GHz
Turbo Clock: up to 4.7 GHz
Base Clock: 100 MHz
Multiplier: 35.0x
Multiplier Unlocked: No
TDP: 58 W
PL1: 58 W
PL2: 110 W
PL2 Tau Limit: 28 seconds

Architecture

Codename: Raptor Lake-R
Generation: Core i3
(Raptor Lake Refresh)
Memory Support: DDR4, DDR5
DDR4 Speed: 3200 MT/s
DDR5 Speed: 4800 MT/s
Memory Bus: Dual-channel
ECC Memory: Yes
PCI-Express: Gen 5, 16 Lanes
(CPU only)
Secondary PCIe: Gen 4, 4 Lanes
Chipsets: Intel 600 Series, Intel 700 Series

Core Config

# of Cores: 4
# of Threads: 8
SMP # CPUs: 1
Integrated Graphics: N/A

Cache

Cache L1: 80 KB (per core)
Cache L2: 1.25 MB (per core)
Cache L3: 12 MB (shared)

Features

  • MMX
  • SSE
  • SSE2
  • SSE3
  • SSSE3
  • SSE4.2
  • AVX
  • AVX2
  • FMA3
  • SHA
  • EIST
  • Intel 64
  • XD bit
  • VT-x
  • VT-d
  • AES-NI
  • TSX
  • TXT
  • CLMUL
  • F16C
  • BMI1
  • BMI2
  • ABM
  • ADX
  • RdRand
  • TBT 2.0
