The AMD Ryzen 7 5700X3D is a desktop processor with 8 cores, launched in January 2024, at an MSRP of $249. It is part of the Ryzen 7 lineup, using the Zen 3 (Vermeer) architecture with Socket AM4. Thanks to AMD Simultaneous Multithreading (SMT) the core-count is effectively doubled, to 16 threads. Ryzen 7 5700X3D has 96 MB of L3 cache and operates at 3 GHz by default, but can boost up to 4.1 GHz, depending on the workload. AMD is building the Ryzen 7 5700X3D on a 7 nm production process using 8,850 million transistors. The silicon die of the chip is not fabricated at AMD, but at the foundry of TSMC. The multiplier is locked on Ryzen 7 5700X3D, which limits its overclocking capabilities.
With a TDP of 105 W, the Ryzen 7 5700X3D consumes a good deal of power, so decent cooling is needed. AMD’s processor supports DDR4 memory with a dual-channel interface. The highest officially supported memory speed is 3200 MT/s, but with overclocking (and the right memory modules) you can go even higher. ECC memory is supported, too, which is an important capability for mission-critical systems, to avoid data corruption. For communication with other components in the machine, Ryzen 7 5700X3D uses a PCI-Express Gen 4 connection. This processor does not have integrated graphics, you will need a separate graphics card.
Hardware virtualization is available on the Ryzen 7 5700X3D, which greatly improves virtual machine performance. Programs using Advanced Vector Extensions (AVX) will run on this processor, boosting performance for calculation-heavy applications. Besides AVX, AMD is including the newer AVX2 standard, too, but not AVX-512.
With a TDP of 105 W, the Ryzen 7 5700X3D consumes a good deal of power, so decent cooling is needed. AMD’s processor supports DDR4 memory with a dual-channel interface. The highest officially supported memory speed is 3200 MT/s, but with overclocking (and the right memory modules) you can go even higher. ECC memory is supported, too, which is an important capability for mission-critical systems, to avoid data corruption. For communication with other components in the machine, Ryzen 7 5700X3D uses a PCI-Express Gen 4 connection. This processor does not have integrated graphics, you will need a separate graphics card.
Hardware virtualization is available on the Ryzen 7 5700X3D, which greatly improves virtual machine performance. Programs using Advanced Vector Extensions (AVX) will run on this processor, boosting performance for calculation-heavy applications. Besides AVX, AMD is including the newer AVX2 standard, too, but not AVX-512.
Physical
Socket: | AMD Socket AM4 |
---|---|
Foundry: | TSMC |
Process Size: | 7 nm |
Transistors: | 8,850 million |
Die Size: | 74 mm² |
I/O Process Size: | 12 nm |
I/O Die Size: | 125 mm² |
Package: | µOPGA-1331 |
tJMax: | 90°C |
Processor
Market: | Desktop |
---|---|
Production Status: | Active |
Release Date: | Jan 8th, 2024 |
Retail Availability: | Jan 31st, 2024 |
Launch Price: | $249 |
Part#: | 100-000001503 100-100001503WOF |
Bundled Cooler: | None |
Performance
Frequency: | 3 GHz |
---|---|
Turbo Clock: | up to 4.1 GHz |
Base Clock: | 100 MHz |
Multiplier: | 30.0x |
Multiplier Unlocked: | No |
TDP: | 105 W |
PPT: | 142 W |
Architecture
Codename: | Vermeer |
---|---|
Generation: | Ryzen 7 (Zen 3 (Vermeer)) |
Memory Support: | DDR4 |
Rated Speed: | 3200 MT/s |
Memory Bus: | Dual-channel |
ECC Memory: | Yes |
PCI-Express: | Gen 4, 20 Lanes (CPU only) |
Chipsets: | AMD 300 Series*, AMD 400 Series, AMD 500 Series |
Core Config
# of Cores: | 8 |
---|---|
# of Threads: | 16 |
SMP # CPUs: | 1 |
Integrated Graphics: | N/A |
Cache
Cache L1: | 64 KB (per core) |
---|---|
Cache L2: | 512 KB (per core) |
Cache L3: | 96 MB (shared) |
Features
|
Notes
Level 3 cache arranged as 32MB 2D cache plus 64MB 3D V-Cache.
*AMD 300 Series chipset support is contingent on vendor updates to AGESA 1.2.0.6b/c. Core overclocking disabled, DRAM/IF frequency tuning remains enabled. ECC modes require motherboard support. |
