The AMD Ryzen 5 8600G is a desktop processor with 6 cores, launched in January 2024, at an MSRP of $229. It is part of the Ryzen 5 lineup, using the Zen 4 (Phoenix) architecture with Socket AM5. Thanks to AMD Simultaneous Multithreading (SMT) the core-count is effectively doubled, to 12 threads. Ryzen 5 8600G has 16 MB of L3 cache and operates at 4.3 GHz by default, but can boost up to 5 GHz, depending on the workload. AMD is building the Ryzen 5 8600G on a 4 nm production process using 25,000 million transistors. The silicon die of the chip is not fabricated at AMD, but at the foundry of TSMC. You may freely adjust the unlocked multiplier on Ryzen 5 8600G, which simplifies overclocking greatly, as you can easily dial in any overclocking frequency.
With a TDP of 65 W, the Ryzen 5 8600G consumes typical power levels for a modern PC. AMD’s processor supports DDR5 memory with a dual-channel interface. The highest officially supported memory speed is 5200 MT/s, but with overclocking (and the right memory modules) you can go even higher. For communication with other components in the computer, Ryzen 5 8600G uses a PCI-Express Gen 4 connection. This processor features the Radeon 760M integrated graphics solution. Inside the box you will not only find the processor, but also a Wraith Stealth cooler.
Hardware virtualization is available on the Ryzen 5 8600G, which greatly improves virtual machine performance. Programs using Advanced Vector Extensions (AVX) will run on this processor, boosting performance for calculation-heavy applications. Besides AVX, AMD has added support for the newer AVX2 and AVX-512 instructions, too.
With a TDP of 65 W, the Ryzen 5 8600G consumes typical power levels for a modern PC. AMD’s processor supports DDR5 memory with a dual-channel interface. The highest officially supported memory speed is 5200 MT/s, but with overclocking (and the right memory modules) you can go even higher. For communication with other components in the computer, Ryzen 5 8600G uses a PCI-Express Gen 4 connection. This processor features the Radeon 760M integrated graphics solution. Inside the box you will not only find the processor, but also a Wraith Stealth cooler.
Hardware virtualization is available on the Ryzen 5 8600G, which greatly improves virtual machine performance. Programs using Advanced Vector Extensions (AVX) will run on this processor, boosting performance for calculation-heavy applications. Besides AVX, AMD has added support for the newer AVX2 and AVX-512 instructions, too.
Physical
Socket: | AMD Socket AM5 |
---|---|
Foundry: | TSMC |
Process Size: | 4 nm |
Transistors: | 25,000 million |
Die Size: | 178 mm² |
Package: | FC-LGA1718 |
tJMax: | 95°C |
Processor
Market: | Desktop |
---|---|
Production Status: | Active |
Release Date: | Jan 8th, 2024 |
Retail Availability: | Jan 31st, 2024 |
Launch Price: | $229 |
Part#: | 100-000001237 |
Bundled Cooler: | Wraith Stealth |
Performance
Frequency: | 4.3 GHz |
---|---|
Turbo Clock: | up to 5 GHz |
Base Clock: | 100 MHz |
Multiplier: | 43.0x |
Multiplier Unlocked: | Yes |
XDNA NPU: | 16 TOPS |
TDP: | 65 W |
Configurable TDP: | 45 W |
PPT: | 61-88 W |
Architecture
Codename: | Phoenix |
---|---|
Generation: | Ryzen 5 (Zen 4 (Phoenix)) |
Memory Support: | DDR5 |
Rated Speed: | 5200 MT/s |
Memory Bus: | Dual-channel |
ECC Memory: | No |
PCI-Express: | Gen 4, 20 Lanes (CPU only) |
Chipsets: | X670E, X670, B650E, B650, A620 |
Core Config
# of Cores: | 6 |
---|---|
# of Threads: | 12 |
SMP # CPUs: | 1 |
Integrated Graphics: | Radeon 760M |
Cache
Cache L1: | 64 KB (per core) |
---|---|
Cache L2: | 1 MB (per core) |
Cache L3: | 16 MB (shared) |
Features
|
Notes
Graphics engine boost clock: 2800MHz |
