The AMD Ryzen 5 8400F is a desktop processor with 6 cores, launched in April 2024, at an MSRP of $170. It is part of the Ryzen 5 lineup, using the Zen 4 (Phoenix) architecture with Socket AM5. Thanks to AMD Simultaneous Multithreading (SMT) the core-count is effectively doubled, to 12 threads. Ryzen 5 8400F has 16 MB of L3 cache and operates at 4.2 GHz by default, but can boost up to 4.7 GHz, depending on the workload. AMD is making the Ryzen 5 8400F on a 4 nm production node using 25,000 million transistors. The silicon die of the chip is not fabricated at AMD, but at the foundry of TSMC. You may freely adjust the unlocked multiplier on Ryzen 5 8400F, which simplifies overclocking greatly, as you can easily dial in any overclocking frequency.
With a TDP of 65 W, the Ryzen 5 8400F consumes typical power levels for a modern PC. AMD’s processor supports DDR5 memory with a dual-channel interface. The highest officially supported memory speed is 5200 MT/s, but with overclocking (and the right memory modules) you can go even higher. For communication with other components in the system, Ryzen 5 8400F uses a PCI-Express Gen 4 connection. This processor does not have integrated graphics, you will need a separate graphics card.
Hardware virtualization is available on the Ryzen 5 8400F, which greatly improves virtual machine performance. Programs using Advanced Vector Extensions (AVX) can run on this processor, boosting performance for calculation-heavy applications. Besides AVX, AMD has added support for the newer AVX2 and AVX-512 instructions, too.
With a TDP of 65 W, the Ryzen 5 8400F consumes typical power levels for a modern PC. AMD’s processor supports DDR5 memory with a dual-channel interface. The highest officially supported memory speed is 5200 MT/s, but with overclocking (and the right memory modules) you can go even higher. For communication with other components in the system, Ryzen 5 8400F uses a PCI-Express Gen 4 connection. This processor does not have integrated graphics, you will need a separate graphics card.
Hardware virtualization is available on the Ryzen 5 8400F, which greatly improves virtual machine performance. Programs using Advanced Vector Extensions (AVX) can run on this processor, boosting performance for calculation-heavy applications. Besides AVX, AMD has added support for the newer AVX2 and AVX-512 instructions, too.
Physical
Socket: | AMD Socket AM5 |
---|---|
Foundry: | TSMC |
Process Size: | 4 nm |
Transistors: | 25,000 million |
Die Size: | 178 mm² |
Package: | FC-LGA1718 |
tJMax: | 95°C |
Processor
Market: | Desktop |
---|---|
Production Status: | Active |
Release Date: | Apr 1st, 2024 |
Retail Availability: | May 14th, 2024 |
Launch Price: | $170 |
Part#: | 100-000001591 |
Performance
Frequency: | 4.2 GHz |
---|---|
Turbo Clock: | up to 4.7 GHz |
Base Clock: | 100 MHz |
Multiplier: | 42.0x |
Multiplier Unlocked: | Yes |
XDNA NPU: | 16 TOPS |
TDP: | 65 W |
Configurable TDP: | 45 W |
PPT: | 61-88 W |
Architecture
Codename: | Phoenix |
---|---|
Generation: | Ryzen 5 (Zen 4 (Phoenix)) |
Memory Support: | DDR5 |
Rated Speed: | 5200 MT/s |
Memory Bus: | Dual-channel |
ECC Memory: | No |
PCI-Express: | Gen 4, 20 Lanes (CPU only) |
Chipsets: | X670E, X670, B650E, B650, A620 |
Core Config
# of Cores: | 6 |
---|---|
# of Threads: | 12 |
SMP # CPUs: | 1 |
Integrated Graphics: | N/A |
Cache
Cache L1: | 64 KB (per core) |
---|---|
Cache L2: | 1 MB (per core) |
Cache L3: | 16 MB (shared) |
Features
|
Notes
Radeon graphics engine disabled. |
