Intel Xeon w7-2475X 20 Cores 40 Threads 225 W TDP 2.6 GHz Frequency 4.8 GHz Boost Sapphire Rapids Codename Socket 4677

Intel Xeon w7-2475X 20 Cores 40 Threads 225 W TDP 2.6 GHz Frequency 4.8 GHz Boost Sapphire Rapids Codename Socket 4677

Original price was: $1,989.00.Current price is: $1,789.00.

Guaranteed Safe Checkout

Features & Compatibility

The Intel Xeon w7-2475X is a server/workstation processor with 20 cores, launched in February 2023, at an MSRP of $1789. It is part of the Xeon W lineup, using the Sapphire Rapids architecture with Socket 4677. Thanks to Intel Hyper-Threading the core-count is effectively doubled, to 40 threads. Xeon w7-2475X has 37.5 MB of L3 cache and operates at 2.6 GHz by default, but can boost up to 4.8 GHz, depending on the workload. Intel is making the Xeon w7-2475X on a 10 nm production node, the transistor count is unknown. You may freely adjust the unlocked multiplier on Xeon w7-2475X, which simplifies overclocking greatly, as you can easily dial in any overclocking frequency.
With a TDP of 225 W, the Xeon w7-2475X is extremely power hungry, which means you need top-notch cooling. Intel’s processor supports DDR5 memory with a quad-channel interface. The highest officially supported memory speed is 4800 MT/s, but with overclocking (and the right memory modules) you can go even higher. ECC memory is supported, too, which is an important capability for mission-critical systems, to avoid data corruption. For communication with other components in the computer, Xeon w7-2475X uses a PCI-Express Gen 5 connection. This processor lacks integrated graphics, you might need a graphics card.
Hardware virtualization is available on the Xeon w7-2475X, which greatly improves virtual machine performance. Additionally, IOMMU virtualization (PCI passthrough) is supported, so that guest virtual machines may directly use host hardware. Programs using Advanced Vector Extensions (AVX) can run on this processor, boosting performance for calculation-heavy applications. Besides AVX, Intel has added support for the newer AVX2 and AVX-512 instructions, too.

Physical

Socket: Intel Socket 4677
Foundry: Intel
Process Size: 10 nm
Package: FC-LGA16A
tCaseMax: 76°C

Processor

Market: Server/Workstation
Production Status: Active
Release Date: Feb 15th, 2023
Launch Price: $1789
Part#: SRM9E

Performance

Frequency: 2.6 GHz
Turbo Clock: up to 4.8 GHz
Turbo Boost 2.0: 4.6 GHz
Base Clock: 100 MHz
Multiplier: 26.0x
Multiplier Unlocked: Yes
TDP: 225 W
Max Turbo Power: 270 W

Architecture

Codename: Sapphire Rapids
Generation: Xeon W
(Sapphire Rapids)
Memory Support: DDR5
Max. Memory: 2 TB (4400 MT/s only)
Rated Speed: 4800 MT/s
Memory Bus: Quad-channel
ECC Memory: Yes
PCI-Express: Gen 5, 64 Lanes
(CPU only)
DMI: 4.0 x8
Chipset: W790

Core Config

# of Cores: 20
# of Threads: 40
AVX-512 FMA Ports: 2
SMP # CPUs: 1
Integrated Graphics: N/A

Cache

Cache L1: 80 KB (per core)
Cache L2: 2 MB (per core)
Cache L3: 37.5 MB

Features

  • MMX
  • SSE
  • SSE2
  • SSE3
  • SSSE3
  • SSE4.2
  • AVX
  • AVX2
  • AVX-512
  • AVX-VNNI
  • FMA3
  • SHA
  • EIST
  • Intel 64
  • XD bit
  • VT-x
  • VT-d
  • AES-NI
  • TSX
  • TXT
  • CLMUL
  • F16C
  • BMI1
  • BMI2
  • ABM
  • ADX
  • AMX
  • RdRand
  • 5-level NPT
  • X2APIC
  • Intel DSA
  • DLBoost 2.0
  • vPro
  • TBT 2.0
  • TBT 3.0

Notes

PCI-Express PHY handles 16-Lanes of PCI-E 5.0 or CXL 1.1, two PHYs per compute die (8 total).

This processor comes with an unlocked multiplier, allowing users to set the multiplier value higher than the shipped value, to facilitate better overclocking.
