Intel Xeon 6745P

Name: Intel Xeon 6745P
SKU: 18538
Availability: InStock

Intel Xeon 6745P
32
Cores
64
Threads
300 W
TDP
3.1 GHz
Frequency
4.3 GHz
Boost
Granite Rapids
Codename
Socket 4710
Socket

Original price was: $5,999.00.Current price is: $5,250.00.

Compare

Add to wishlist

Guaranteed Safe Checkout

Features & Compatibility

The Intel Xeon 6745P is a server/workstation processor with 32 cores, launched in February 2025, at an MSRP of $5250. It is part of the Xeon 6 lineup, using the Granite Rapids-SP architecture with Socket 4710. Thanks to Intel Hyper-Threading the core-count is effectively doubled, to 64 threads. To further increase overall system performance, up to two Xeon 6745P CPUs can work together in a multi-processor (SMP) configuration. Xeon 6745P has 336 MB of L3 cache and operates at 3.1 GHz by default, but can boost up to 4.3 GHz, depending on the workload. Intel is making the Xeon 6745P on a 5 nm production node, the transistor count is unknown. The multiplier is locked on Xeon 6745P, which limits its overclocking potential.
With a TDP of 300 W, the Xeon 6745P is extremely power hungry, which means you need top-notch cooling. Intel’s processor supports DDR5 memory with an eight-channel interface. The highest officially supported memory speed is 6400 MT/s. ECC memory is supported, too, which is an important capability for mission-critical systems, to avoid data corruption. For communication with other components in the system, Xeon 6745P uses a PCI-Express Gen 5 connection. This processor lacks integrated graphics, you might need a graphics card.
Hardware virtualization is available on the Xeon 6745P, which greatly improves virtual machine performance. Additionally, IOMMU virtualization (PCI passthrough) is supported, so that guest virtual machines may directly use host hardware. Programs using Advanced Vector Extensions (AVX) can run on this processor, boosting performance for calculation-heavy applications. Besides AVX, Intel has added support for the newer AVX2 and AVX-512 instructions, too.

Physical

Socket:	Intel Socket 4710
Foundry:	Intel
Process Size:	5 nm
I/O Process Size:	10 nm
Die Size:	2x 598 mm²
I/O Die Size:	2x 241 mm²
Package:	FC-LGA18N
tCaseMax:	78°C
tJMax:	97°C

Processor

Market:	Server/Workstation
Production Status:	Active
Release Date:	Feb 24th, 2025
Launch Price:	$5250
Part#:	SRWPA Q7L9
Bundled Cooler:	None

Performance

Frequency:	3.1 GHz
All Core Turbo:	4.1 GHz
Turbo Clock:	up to 4.3 GHz
Base Clock:	100 MHz
Multiplier:	31.0x
Multiplier Unlocked:	No
TDP:	300 W

Architecture

Codename:	Granite Rapids
Generation:	Xeon 6 (Granite Rapids-SP)
Memory Support:	DDR5
Max. Memory:	4 TB
Rated Speed:	6400 MT/s
2 DPC RAM Speed:	5200 MT/s
MCR DIMM Speed:	8000 MT/s
Memory Bus:	Eight-channel
ECC Memory:	Yes
PCI-Express:	Gen 5, 88 Lanes (CPU only)
CXL:	Gen 2.0, 64 Lanes (Shared with PCI-E)
UPI Links:	4 x24 24 GT/s

Core Config

# of Cores:	32
# of Threads:	64
AVX-512 FMA Ports:	2
SMP # CPUs:	2
Integrated Graphics:	N/A

Cache

Cache L1:	112 KB (per core)
Cache L2:	2 MB (per core)
Cache L3:	336 MB (shared)

Features

MMX
SSE
SSE2
SSE3
SSSE3
SSE4.2
AVX
AVX2
AVX-512
AVX-VNNI
FMA3
SHA
EIST
Speed Shift
HTT
Intel 64
XD bit
VT-x
VT-x EPT
VT-d
AES-NI
TSX
TXT
CLMUL
F16C
BMI1
BMI2
ABM
ADX
AMX
RdRand
5-level NPT
X2APIC
Intel DSA (4)
QAT (4)
DLB (4)
IAA (4)
TDX
TME
SGX (512GB)
RDT
VROC
QuickAssist
DLBoost 3.0
Speed Select
TBT 2.0

Notes

CXL 2.0 supports Type 3 devices which can provide significant increases to system attached DRAM capacity.

Speed Select Technology – Performance Profiles:
6745P (0) – 32 Active Cores @ 3.1 GHz 300 W
6475P (1) – 32 Active Cores @ 3.6 GHz 300 W

Name	Codename	Cores	Clock	Socket	Process	L3 Cache	TDP
Xeon 6315P	Raptor Lake-R	4	2.8 to 4.7 GHz	Socket 1700	10 nm	12 MB	55 W
Xeon 6325P	Raptor Lake-R	4 / 8	3.5 to 5.2 GHz	Socket 1700	10 nm	12 MB	55 W
Xeon 6333P	Raptor Lake-R	6 / 12	3.1 to 5.2 GHz	Socket 1700	10 nm	18 MB	65 W
Xeon 6337P	Raptor Lake-R	6 / 12	3.5 to 5.3 GHz	Socket 1700	10 nm	18 MB	80 W
Xeon 6349P	Raptor Lake-R	6 / 12	3.6 to 5.7 GHz	Socket 1700	10 nm	18 MB	95 W
Xeon 6353P	Raptor Lake-R	8 / 16	2.7 to 5.4 GHz	Socket 1700	10 nm	24 MB	65 W
Xeon 6357P	Raptor Lake-R	8 / 16	3 to 5.4 GHz	Socket 1700	10 nm	24 MB	80 W
Xeon 6369P	Raptor Lake-R	8 / 16	3.3 to 5.7 GHz	Socket 1700	10 nm	24 MB	95 W
Xeon 6503P-B	Granite Rapids	12 / 24	2 to 3.5 GHz	BGA 4368	5 nm	48 MB	110 W
Xeon 6505P	Granite Rapids	12 / 24	2.2 to 4.1 GHz	Socket 4710	5 nm	48 MB	150 W
Xeon 6507P	Granite Rapids	8 / 16	3.5 to 4.3 GHz	Socket 4710	5 nm	48 MB	150 W
Xeon 6511P	Granite Rapids	16 / 32	2.3 to 4.2 GHz	Socket 4710	5 nm	72 MB	150 W
Xeon 6513P-B	Granite Rapids	20 / 40	2 to 3.3 GHz	BGA 4368	5 nm	80 MB	130 W
Xeon 6515P	Granite Rapids	16 / 32	2.3 to 3.8 GHz	Socket 4710	5 nm	72 MB	150 W
Xeon 6516P-B	Granite Rapids	20 / 40	2.3 to 3.5 GHz	BGA 4368	5 nm	80 MB	145 W
Xeon 6517P	Granite Rapids	16 / 32	3.2 to 4.2 GHz	Socket 4710	5 nm	72 MB	190 W
Xeon 6520P	Granite Rapids	24 / 48	2.4 to 4 GHz	Socket 4710	5 nm	144 MB	210 W
Xeon 6521P	Granite Rapids	24 / 48	2.6 to 4.1 GHz	Socket 4710	5 nm	144 MB	225 W
Xeon 6523P-B	Granite Rapids	24 / 48	2.5 to 3.9 GHz	BGA 4368	5 nm	96 MB	175 W
Xeon 6527P	Granite Rapids	24 / 48	3 to 4.2 GHz	Socket 4710	5 nm	144 MB	255 W
Xeon 6530P	Granite Rapids	32 / 64	2.3 to 4.1 GHz	Socket 4710	5 nm	144 MB	225 W
Xeon 6533P-B	Granite Rapids	32 / 64	2.2 to 3.9 GHz	BGA 4368	5 nm	128 MB	205 W
Xeon 6543P-B	Granite Rapids	32 / 64	2 to 3.3 GHz	BGA 4368	5 nm	128 MB	160 W
Xeon 6546P-B	Granite Rapids	32 / 64	2.3 to 3.5 GHz	BGA 4368	5 nm	128 MB	195 W
Xeon 6553P-B	Granite Rapids	36 / 72	2.6 to 4 GHz	BGA 4368	5 nm	144 MB	235 W
Xeon 6556P-B	Granite Rapids	36 / 72	2.3 to 3.5 GHz	BGA 4368	5 nm	144 MB	215 W
Xeon 6563P-B	Granite Rapids	38 / 76	2.4 to 4 GHz	BGA 4368	5 nm	152 MB	235 W
Xeon 6706P-B	Granite Rapids	40 / 80	2.5 to 3.5 GHz	BGA 4368	5 nm	160 MB	235 W
Xeon 6714P	Granite Rapids	8月16日	4 to 4.3 GHz	Socket 4710	5 nm	48 MB	165 W
Xeon 6716P-B	Granite Rapids	40 / 80	2.3 to 3.5 GHz	BGA 4368	5 nm	160 MB	235 W
Xeon 6724P	Granite Rapids	16 / 32	3.6 to 4.3 GHz	Socket 4710	5 nm	72 MB	210 W
Xeon 6726P-B	Granite Rapids	42 / 84	2.3 to 3.5 GHz	BGA 4368	5 nm	168 MB	235 W
Xeon 6728P	Granite Rapids	24 / 48	2.7 to 4.1 GHz	Socket 4710	5 nm	144 MB	210 W
Xeon 6730P	Granite Rapids	32 / 64	2.5 to 3.8 GHz	Socket 4710	5 nm	288 MB	250 W
Xeon 6731P	Granite Rapids	32 / 64	2.5 to 4.1 GHz	Socket 4710	5 nm	144 MB	245 W
Xeon 6736P	Granite Rapids	36 / 72	2 to 4.1 GHz	Socket 4710	5 nm	144 MB	205 W
Xeon 6737P	Granite Rapids	32 / 64	2.9 to 4 GHz	Socket 4710	5 nm	144 MB	270 W
Xeon 6738P	Granite Rapids	32 / 64	2.9 to 4.2 GHz	Socket 4710	5 nm	144 MB	270 W
Xeon 6740P	Granite Rapids	48 / 96	2.1 to 3.8 GHz	Socket 4710	5 nm	288 MB	270 W
Xeon 6741P	Granite Rapids	48 / 96	2.5 to 3.8 GHz	Socket 4710	5 nm	288 MB	300 W
Xeon 6745P	Granite Rapids	32 / 64	3.1 to 4.3 GHz	Socket 4710	5 nm	336 MB	300 W
Xeon 6747P	Granite Rapids	48 / 96	2.7 to 3.9 GHz	Socket 4710	5 nm	288 MB	330 W
Xeon 6748P	Granite Rapids	48 / 96	2.5 to 4.1 GHz	Socket 4710	5 nm	192 MB	300 W
Xeon 6760P	Granite Rapids	64 / 128	2.2 to 3.8 GHz	Socket 4710	5 nm	320 MB	330 W
Xeon 6761P	Granite Rapids	64 / 128	2.5 to 3.9 GHz	Socket 4710	5 nm	336 MB	350 W
Xeon 6767P	Granite Rapids	64 / 128	2.4 to 3.9 GHz	Socket 4710	5 nm	336 MB	350 W
Xeon 6768P	Granite Rapids	64 / 128	2.4 to 3.9 GHz	Socket 4710	5 nm	336 MB	330 W
Xeon 6781P	Granite Rapids	80 / 160	2 to 3.8 GHz	Socket 4710	5 nm	336 MB	350 W
Xeon 6787P	Granite Rapids	86 / 172	2 to 3.8 GHz	Socket 4710	5 nm	336 MB	350 W
Xeon 6788P	Granite Rapids	86 / 172	2 to 3.8 GHz	Socket 4710	5 nm	336 MB	350 W
Xeon 6944P	Granite Rapids	72 / 144	1.8 to 3.9 GHz	Socket 7529	5 nm	432 MB	350 W
