The Intel Core i9-14901TE is a desktop processor with 8 cores, launched in July 2024. It is part of the Core i9 lineup, using the Raptor Lake Refresh architecture with Socket 1700. Thanks to Intel Hyper-Threading the core-count is effectively doubled, to 16 threads. Core i9-14901TE has 36 MB of L3 cache and operates at 2.3 GHz by default, but can boost up to 5.5 GHz, depending on the workload. Intel is making the Core i9-14901TE on a 10 nm production node, the transistor count is unknown. The multiplier is locked on Core i9-14901TE, which limits its overclocking potential.
With a TDP of 45 W, the Core i9-14901TE consumes typical power levels for a modern PC. Intel’s processor supports DDR4 and DDR5 memory with a dual-channel interface. ECC memory is supported, too, which is an important capability for mission-critical systems, to avoid data corruption. For communication with other components in the machine, Core i9-14901TE uses a PCI-Express Gen 5 connection. This processor features the UHD Graphics 770 integrated graphics solution.
Hardware virtualization is available on the Core i9-14901TE, which greatly improves virtual machine performance. Additionally, IOMMU virtualization (PCI passthrough) is supported, so that guest virtual machines may directly use host hardware. Programs using Advanced Vector Extensions (AVX) can run on this processor, boosting performance for calculation-heavy applications. Besides AVX, Intel is including the newer AVX2 standard, too, but not AVX-512.
With a TDP of 45 W, the Core i9-14901TE consumes typical power levels for a modern PC. Intel’s processor supports DDR4 and DDR5 memory with a dual-channel interface. ECC memory is supported, too, which is an important capability for mission-critical systems, to avoid data corruption. For communication with other components in the machine, Core i9-14901TE uses a PCI-Express Gen 5 connection. This processor features the UHD Graphics 770 integrated graphics solution.
Hardware virtualization is available on the Core i9-14901TE, which greatly improves virtual machine performance. Additionally, IOMMU virtualization (PCI passthrough) is supported, so that guest virtual machines may directly use host hardware. Programs using Advanced Vector Extensions (AVX) can run on this processor, boosting performance for calculation-heavy applications. Besides AVX, Intel is including the newer AVX2 standard, too, but not AVX-512.
Physical
Socket: | Intel Socket 1700 |
---|---|
Foundry: | Intel |
Process Size: | 10 nm |
Die Size: | 257 mm² |
Package: | FC-LGA16A |
tJMax: | 100°C |
Processor
Market: | Desktop |
---|---|
Production Status: | Active |
Release Date: | Jul 2024 |
Part#: | Q49C SRNJJ |
Bundled Cooler: | None |
Performance
Frequency: | 2.3 GHz |
---|---|
Turbo Clock: | up to 5.5 GHz |
P-Core Turbo: | 5.5 GHz |
Base Clock: | 100 MHz |
Multiplier: | 23.0x |
Multiplier Unlocked: | No |
TDP: | 45 W |
PL1: | 45 W |
PL2: | 115 W |
PL2 Tau Limit: | 28 seconds |
Architecture
Codename: | Raptor Lake-R |
---|---|
Generation: | Core i9 (Raptor Lake Refresh) |
Memory Support: | DDR4, DDR5 |
DDR4 Speed: | 3200 MT/s |
DDR5 Speed: | 5600 MT/s |
Memory Bus: | Dual-channel |
ECC Memory: | Yes |
PCI-Express: | Gen 5, 16 Lanes (CPU only) |
Secondary PCIe: | Gen 4, 4 Lanes |
Chipsets: | Intel 600 Series, Intel 700 Series |
Core Config
# of Cores: | 8 |
---|---|
# of Threads: | 16 |
SMP # CPUs: | 1 |
Integrated Graphics: | UHD Graphics 770 |
Cache
Cache L1: | 80 KB (per core) |
---|---|
Cache L2: | 2 MB (per core) |
Cache L3: | 36 MB (shared) |
Features
|
Notes
Intel UHD Graphics Dynamic Frequency: 300-1650MHz
Embedded segment. |
