The Intel Core Ultra 5 135UL is a desktop processor with 12 cores, launched in April 2024, at an MSRP of $331. It is part of the Ultra 5 lineup, using the Meteor Lake-PS architecture with Socket 1851. Intel Hyper-Threading technology is available and effectly doubles the core-count of the P-Cores, to a total of 14 threads. Core Ultra 5 135UL has 12 MB of L3 cache and operates at 1600 MHz by default, but can boost up to 4.4 GHz, depending on the workload. Intel is building the Core Ultra 5 135UL on a 7 nm production process, the transistor count is unknown. The multiplier is locked on Core Ultra 5 135UL, which limits its overclocking capabilities.
With a TDP of 15 W, the Core Ultra 5 135UL consumes very little energy. Intel’s processor supports DDR5 memory with a dual-channel interface. The highest officially supported memory speed is 5600 MT/s, but with overclocking (and the right memory modules) you can go even higher. Actual memory technology support depends on the chosen motherboard, the processor itself supports multiple memory types, but most motherboards have only one kind of slot. For communication with other components in the computer, Core Ultra 5 135UL uses a PCI-Express Gen 4 connection. This processor features the Arc Xe-LPG 64EU integrated graphics solution.
Hardware virtualization is available on the Core Ultra 5 135UL, which greatly improves virtual machine performance. Additionally, IOMMU virtualization (PCI passthrough) is supported, so that guest virtual machines may directly use host hardware. Programs using Advanced Vector Extensions (AVX) will run on this processor, boosting performance for calculation-heavy applications. Besides AVX, Intel is including the newer AVX2 standard, too, but not AVX-512.
With a TDP of 15 W, the Core Ultra 5 135UL consumes very little energy. Intel’s processor supports DDR5 memory with a dual-channel interface. The highest officially supported memory speed is 5600 MT/s, but with overclocking (and the right memory modules) you can go even higher. Actual memory technology support depends on the chosen motherboard, the processor itself supports multiple memory types, but most motherboards have only one kind of slot. For communication with other components in the computer, Core Ultra 5 135UL uses a PCI-Express Gen 4 connection. This processor features the Arc Xe-LPG 64EU integrated graphics solution.
Hardware virtualization is available on the Core Ultra 5 135UL, which greatly improves virtual machine performance. Additionally, IOMMU virtualization (PCI passthrough) is supported, so that guest virtual machines may directly use host hardware. Programs using Advanced Vector Extensions (AVX) will run on this processor, boosting performance for calculation-heavy applications. Besides AVX, Intel is including the newer AVX2 standard, too, but not AVX-512.
Physical
Socket: | Intel Socket 1851 |
---|---|
Foundry: | Intel |
Process Size: | 7 nm |
SoC Tile Process: | TSMC N6 |
I/O Tile Process: | TSMC N6 |
Graphics Tile Process: | TSMC N5 |
Package: | FC-LGA18V |
tJMax: | 105°C |
Processor
Market: | Desktop |
---|---|
Production Status: | Active |
Release Date: | Apr 8th, 2024 |
Launch Price: | $331 |
Part#: | SRN97 |
Performance
Frequency: | 1600 MHz |
---|---|
Turbo Clock: | up to 4.4 GHz |
E-Core Frequency: | 1100 MHz up to 3.6 GHz |
LP E-Core Frequency: | 700 MHz up to 2.1 GHz |
Base Clock: | 100 MHz |
Multiplier: | 16.0x |
Multiplier Unlocked: | No |
AI Boost NPU: | 1.4 GHz |
TDP: | 15 W |
Maximum Power: | 57 W |
Minimum Power: | 12 W |
Architecture
Codename: | Meteor Lake-PS |
---|---|
Generation: | Ultra 5 (Meteor Lake-PS) |
Memory Support: | DDR5 Depends on motherboard |
Rated Speed: | 5600 MT/s |
Memory Bus: | Dual-channel |
ECC Memory: | No |
PCI-Express: | Gen 4, 8 Lanes (CPU only) |
Secondary PCIe: | Gen 4, 3×4 Lanes |
Core Config
# of Cores: | 12 |
---|---|
# of Threads: | 14 |
Hybrid Cores: | P-Cores: 2 E-Cores: 10 |
LP E-Cores: | 2 |
SMP # CPUs: | 1 |
Integrated Graphics: | Arc Xe-LPG 64EU |
Cache
Cache L1: | 112 KB (per core) |
---|---|
Cache L2: | 2 MB (per core) |
Cache L3: | 12 MB (shared) |
E-Core L1: | 96 KB (per core) |
E-Core L2: | 2 MB (per module) |
Features
|
Notes
Intel Arc Xe-LPG Graphics Dynamic Frequency: 1900 MHz
“Redwood Cove” P-Cores |
