Altus XE4218GTS Server Features
- Dual AMD EPYC™ Processors at up to 240W each for performance configurations
- NVIDIA® Delta Baseboard (8x A100-SXM) for high-end data analytics and artificial intelligence workloads at scale
- Storage density of up to eight 2.5” drive bays, with support for U.2 NVMe drives
- Eight PCIe Gen4 x16 low profile slots
Altus XE4218GTS Technical Specs
| FORM FACTOR | |
| Form Factor | 4U Rackmount |
| PROCESSORS | |
| Processor Number | 2 |
| Processor Type | AMD EPYC 7002/7003 |
| Maximum TDP | 240 |
| MOTHERBOARD | |
| Board Management | |
| BMC Chipset | ASpeed AST2500 |
| Dedicated BMC Interface | Yes |
| IPMI 2.0 | Yes |
| KVM Over LAN | Yes |
| RedFish | Yes |
| Chipset | SoC |
| MEMORY | |
| Memory Type | DDR4-3200MHz ECC |
| Memory Capacity | Up to 4TB (32x DIMMs) |
| STORAGE SYSTEM | |
| Hard Drive Bays | |
| 2.5″ | 6 |
| U.2 NVMe (2.5″) | 6 |
| M.2 NVMe | 2 |
| Hard Drive Backplane | 12Gb/NVMe |
| NETWORKING | |
| Ethernet Controller | Intel I550 |
| On-Board LAN | 2x 10GbE/RJ45 |
| PCI EXPANSION SLOTS | |
| Number of Slots/Gen/Speed (Size) | 10x PCIe Gen4 x16 (HHHL) |
| GPU | |
| GPU Capable | Yes |
| Supported GPUs | |
| NVIDIA | NVIDIA HGX A100 8-GPU 80GB |
| EXTERNAL I/O INTERFACES | |
| USB Ports | 2x USB 3.0 |
| VGA Ports | Yes |
| SUPPORTED OPERATING SYSTEM | |
| Supported OS | RHEL, CentOS |
| POWER SYSTEM | |
| Power Supply Size | 4x 3000W 80Plus Platinum |
| MOUNTING HARDWARE | |
| Rackmount Rails | Standard Rails included |
| OPERATING ENVIRONMENT | |
| Operating Temperature | 10C to 35C (50F to 95F) |
| Non-operating Temperature | 0C to 60C (32F to 140F) |
| Operating Relative Humidity | 8% to 80% (non-condensing) |
| Non-operating Relative Humidity | 20% to 95% (non-condensing) |
| SYSTEM DIMENSIONS & WEIGHT | |
| Height | 6.93 inches |
| Width | 17.60 inches |
| Depth | 35.43 inches |
| Machine Weight | Approximately 130 lbs |
| Shipping Weight | Approximately 150 lbs |
| WARRANTY | |
| Warranty | 3 Year Standard; Up to 4 years on-site available |
